Universal Testing Machines

Technical Data : Universal Testing M/C
Model Unit UTE-10 UTE-20 UTE-40 UTE-60 UTE-100 UTE-200
Maximum Capacity kN 100 200 400 600 1000 2000
Measuring Range kN 0-100 0-200 0-400 0-600 0-1000 0-2000
Load Resolution ( 20,000 counts full scale ) N 5 10 20 30 50 100
Load Range with accuracy of measurement ± 1.0% kN 2 to 100 4 to 200 8 to 400 12 to 600 20 to 1000 40 to 2000
Resolution of piston movement ( Displacement ) mm 0.1 0.1 0.1 0.1 0.1 0.1
Clearance For Tensile at Fully descended working piston mm 50-700 50-700 50-700 50-800 50-850 50-900
Clearance For compression test at Fully descended working piston mm 0-700 0-700 0-700 0-800 0-850 0-900
Clearance between columns mm 500 500 500 600 750 850
Ram Stroke mm 150 200 200 250 250 300
Straining / Piston speed ( at no load ) Mm/min 0-300 0-150 0-150 0-100 0-80 0-45


Rockwell Hardness Testers

rockwell-hardness-testers.jpgs

Technical Data : Rockwell Hardness
Model Unit RAS RASM RAB-1 RAB-250 TWIN
Load kgf. 60, 100, 150 60, 100, 150 60, 100, 150, 187, 5 250 60, 100, 150, 187, 5 250 15, 30, 45 ( Rockwell Superficial )
60, 100, 150 ( Rockwell )
Initial Load kgf. 10 10 10 10 3 ( Rockwell Superficial)
10 ( Rockwell )
Max. test Height mm 230 230 230 330 330
Depth of Throat mm 133 133 133 133 150
Max. dept of elevating screw below base mm 240 240 240 355 355
Size of base ( Approx ) mm 170 x 430 170 x 430 170 x 230 210 x 474 210 x 474
Machine Height ( Approx ) mm 655 655 655 850 850
Nett Weight ( Approx ) kg. 65 65 65 100 100

Brinell Hardness Testers

Technical Data : Brinell Hardness
Model Unit B 3000 ( o ) B 3000 ( J ) B 3000 ( H )
Load   500 to 3000 in Stages of 250 500 to 3000 in Stages of 250 500 to 3000 in Stages of 250
Initial Load kgf. Nil Nil 250
Max. test Height mm 380 254 410
Depth of Throat mm 200 150 200
Max. dept of elevating screw below base mm 180 0 180
Size of base mm 370 x 670 255 x 495 370 x 670
Machine Height ( Approx ) mm 1185 860 1127
Nett Weight ( Approx ) mm 500 210 450
Drive Motor HP 0.33 - 415 v/p Nil 0.33 - 415v/p
brinell-hardness-testers

Vicker Hardness Testers

vicker-hardness-tester
Technical Data : Vicker Hardness
Test Loads 5, 10, 20, 30, 50 kg
Magnification of optical projection 70*
Max. Test Height ( mm ) 200
Scale least count ( mm ) 0.001
Depth of thorat ( mm ) 133
Dimensions of machine ( mm ) L - 585* W - 290* H - 860
Weight ( Approx ) 73kg.
Powar Supply 220v AC, 50Hz, 1-phase

Impact Testers

Technical Data : Impact
Model IT - 30 IT - 30 ( D ) IT - 30 ( ASTM ) Charpy Test IT - 1.5 IT - 0.5
Maximum Capacity 300 J / 168 J 300 J / 168 J 300 J 15 J 5 J
Maximum Scale Graduation 2 J 0.5 J 2 J 0.1 J 0.05 J

impact-tester
